HML Equipment information and specification

HML Bonding press The LP 1000 series

This  Systems  are  in ALU  Version  ( Automatic Loading / Unloading    )   which shows  a maximum  capacity  and  efficence  at  a  low need of floor capacity.This  system  came  all  at  300°  C  maximum heat  capacity.

Enquire now
Call our global sales and customer support team on +44 (0) 2380 667 486 for more information.

2

Features and benefits

Can be customised

Easy operation

High accuracy

High quality

Information

Machine Model
Bonding press The LP 1000 series
Manufacturer
HML
Key Features
Can be customised, Easy operation, High accuracy, High quality

Description:

The  LP  1000  Series  marks  the  top  in  our  Press  Portfolio. Available  in  versions  of  2,3  & 4  openings  as  electrical  heated  version  and  4 or   6   opening   in   Thermo   Oil   version1300 x 1050 x 1950,

this Series  comes  with  a  usable  laminatiing  area of  600  x  750  mm  and  a  max.  press  capacity of 150 tons.

G. System Specifications
Technical Data
Specification
Number of opening
4
Pressure Force ( kN )
1250 ( Option 1500 )
Width of opening(mm)
95
Max. laminator surface(mm)
620 x 710
Max. temperature(℃)
300 ( Option 400 )
Measurements L x W x H(mm)-Machine
1300 x 1050 x 1950
Measurements L x W x H(mm)-Hydraulic & Vacuum
980 x 700 x 800
Measurements L x W x H(mm)-Processing Unit / Electrical
800 x 400 x 1950
