iVision Extrusion Line iV3 (from 2.2KW)
Vacuum system designed specifically for light metals and plastics
Call our global sales and customer support team on +44 (0) 2380 667 486 for more information.
Features and benefits
1 year warranty
High efficiency
High quality
Latest technology
Information
Machine Model
Extrusion Line iV3 (from 2.2KW)
Manufacturer
iVision
Key Features
1 year warranty, High efficiency, High quality, Latest technology
Description:
Vacuum range developed with cetrifugal fans dedicated to the extrusion working industry. The series is suitable for all machines that cut, drill or mill, producing chips in large quantities that need removal.
Extrusion Line iV3-2.2-160-1400 Technical SpecificationsTechnical Data
Specification
Frequency
50HZ
Power
2.2KW
Voltage
variable
Water lift max
30mbar
Air flow max
1400m³/h
No. of inlet
2
Suction inlet
Ø100mm
Volume
160L
Machine dimensions
203 x 91 x 84cm (HLW)
Machine weight
125kg
Technical Data
Specification
Frequency
60HZ
Power
26KW
Water lift max
150mbar
Air flow max
4400m³/h
No. of inlet
2
Suction inlet
Ø160mm
Volume
160L
Machine dimensions
279 x 174 x 130cm (HLW)
Machine weight
450kg
For further information about our range of Vacuums, or parts available on these products call us on +44 (0) 2380 667 486
