Unicomp AX8500 LED X-Ray Inspection Equipment
Low cost, high-performance AX8500 x-ray inspection system
Call our global sales and customer support team on +44 (0) 2380 667 486 for more information.
Features and benefits
1 year warranty
Easy operation
Outstanding reliability
Information
Machine Model
AX8500 LED X-Ray Inspection Equipment
Manufacturer
Unicomp
Key Features
1 year warranty, Easy operation, Outstanding reliability
Description:
The AX8500 X Ray Inspection System is a full featured high-performance x-ray inspection system with an unbeatable price to performance ratio and includes all of the advanced features you would expect to find on a much more expensive x-ray inspection system.
G. System SpecificationsTechnical Data
Specification
X-Ray tube max. voltage, type
110kV, closed
X-Ray tube power consumption
25W
X-Ray tube focal spot size
5µm
X-Ray tube magnification
1600X
Detector type
FPD
Detector resolution
101 LP/cm
Effective area
58 x 54mm
Max. loading area
φ570mm
Max. inspection area
450 x 450mm
Max. loading weight
10kg
Motion range (up and down)
200mm
Table tilting angle
±45° (Z-axis), 360° (X, Y-axis)
Machine dimensions
1370 x 1300 x 1700mm (WDH)
Machine weight
1500kg
For further information about our range of Inspection equipment, or parts available on these products call us on +44 (0) 2380 667 486
